Controls, Indicators, and Configuration

This chapter shows the locations and describes the functions of the library

storage module (LSM) operator panel and the power switch. It also shows how

to set the Small Computer Systems Interface (SCSI) address and the maximum

usage count of the cleaning cartridges. Refer to the drive publications for

information about operating the drives.

The LSM operator panel is on the right front door of the LSM. The panel

contains softkeys and indicators, plus a two-line display. The LSM operator

panel shows LSM status, configuration, test sequences, and error information.

Figure 2-1

You use this panel to:

• Resolve machine problems.

If an error occurs, the display shows a fault symptom code (FSC) that you

can give to the customer engineer to help resolve problems. Write down the

FSC as soon as it is displayed.

• Receive instructions to close the door or cartridge access port (CAP).

• Set the SCSI robotic address.

• Set the maximum usage count of the cleaning cartridge.

shows the panel and describes each item.

2-1
