Operating in Manual Mode
Rotating the Z Column
If you need to rotate the Z column, grasp it and carefully rotate it, as shown in
Figure
3-5.
The Z column does not rotate the full 360 degrees. If the Z column meets
resistance and stops before the desired position is reached, it has contacted a
stopping mechanism. Do not force it. Rotate the column in the opposite
direction.

Figure 3-5. Rotating the Z Column

H_E60034
3-11
