The oven light is a standard 40-watt appliance bulb. It will come
on when the oven door is open. It will not work dueng the Self-
Cleaning cycle. When the oven door is closed Dress the OVEN
3ad to turn on and off
3efore reDlacing, make sure the oven and cooktoD are cool and
the control knobs are off.
To Replace:
1. Unplug range or a_sconnect Dower
2. Turn the glass bulb cover m the back of the oven
counterclockwise [o remove
3. Turn bulb counterclockwise to remove from socket,
4. Replace bulb then bulb cover By [urnmg cloct{wBe.
5. Plug in range or reconnect power.
4. To remove starter turn it counterclockwise and lift out of its
rnounung Base.
5. To remove bulb roll it forward or backward 90 ° until it clicks
then lift out
To Install Starter and/or Bulb:
1. Fit starter prongs into starter mounting Base and [urn
clockwise,
2. Slide bulb prongs into bulb mounting base ends. Roll the bulb
forward or backward 90 ° until it clicks.
The console night light is located at the tOD of the Electronic
Oven Control panel It has two reDlaceable Darts. The fluorescent
light bulb is a standard F8T5 miniature fluorescent lamp, The
starter is the knob-shaDed Dart to the left of the light bulb, It is a
s[anaara FS-5C starter. The console night light will not work
aunng the self-cleaning cycle,
To turn on and off: Press the TOP 3an.
To Remove Starter and/or Bulb:
1. Unplug range or a_sconnec[ Dower
2. Push down with thumbs on the front of the lens cover while
pulling up with fingers on the back of the lens coven
3. Push down on the left end of the bulb mounDng base. When
the assembly latches =twill click
4. Replace lens cover. Position the two rear lees cover tabs in
front of the two metal sDnng cI_ps (located directly 3ehind the
bulb) Push back ann down on the lens cover to lock into
position.
3.
/ 5. Plug m range or reconnec[ power.
Push release lever toward bulb. The left end of the light
assembly will raise up.
1 2 3
J
J
1. Starter
2. Release lever
3. Bulb
