T
Go to step 5.
3. If swapping a hard disk drive, remove its carrier from the SCSI hard disk drive bay
and perform the following procedures:
Depending on the drive fault, the drive may be still spinning when
you remove it. Follow the next steps exactly when removing drives.
T
Pull the disk carrier handle out.
T
Pull the faulty disk drive out of the bay far enough to disengage the drive
connector from the backplane. Wait 30 seconds until the drive spins down.
T
Remove the carrier from the drive bay.
4. Remove the hard disk drive from the disk carrier.
5. Remove the new drive from its protective wrapper, and place on an antistatic
surface.
Observe static precautions. Use an antistatic wrist strap.
6. Record the drive model and serial numbers in the equipment log.
7. Install the drive on the drive carrier.
4-20 Upgrading Your System
Figure 4-11 Removing the Disk Carrier's Front Panel
! CAUTION
! CAUTION
