System Board Features

Figure 1-5 shows the major components on the system board, while the following
summarizes the board features.
Board set summary
Multiple processor support
Upgradable memory
Add-in board support
IDE controller
SCSI controller
BIOS
Video
External device
connectors
Clock
System hardware
monitoring
Configuration utilities
Feature description
Two processor sockets; up to two Pentium II microprocessors on the system
board.
Four DIMM sockets on the system board, supporting up to 512 MB memory
using 128 MB DIMMs.
Three dedicated ISA bus slots on the system board. Two dedicated 32-bit
PCI slots on the system board. One shared PCI/ISA slot on the system
board.
Onboard IDE controller.
Onboard SCSI-2; ultra wide SCSI channel and narrow SCSI channel
support (PCI-based).
Flash memory-based BIOS (Basic Input/Output System ) and Setup utilities.
Integrated super VGA controller ships with 2 MB of video memory.
Onboard connectors for two serial ports, parallel port, PS/2-compatible
keyboard and mouse, and VGA monitor.
Real-time clock/calendar (RTC).
Detects chassis intrusion and contains sensors for temperature, voltage, and
fan failure.
Resource Configuration Utility (RCU), BIOS Setup, SCSISelect Utility, and
Event Log Reader.
System Overview 1-7
