Pin List and Signal Description
Table 23. Alphabetical Pin Assignment
Pin Name
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESET#
RS0#
RS1#
RS2#
RSP#
SKTOCC#
SLP#
SMI#
STPCLK#
TCK
TDI
TDO
TESTHI0
TESTHI1
TESTHI2
TESTHI3
TESTHI4
TESTHI5
TESTHI6
TESTHI7
TESTHI8
TESTHI9
TESTHI10
TESTHI11
TESTHI12
THERMDA
THERMDC
THERMTRIP#
TMS
TRDY#
TRST#
VCC
VCC
VCC
VCC
VCC
44
Signal Buffer
Pin # Direction
Type
A22
A7
AE21
AF24
AF25
AB25 Common Clock Input
F1 Common Clock Input
G5 Common Clock Input
F4 Common Clock Input
AB2 Common Clock Input
AF26 Power/Other Output
AB26 Asynch GTL+ Input
B5 Asynch GTL+ Input
Y4 Asynch GTL+ Input
D4 TAP Input
C1 TAP Input
D5 TAP Output
AD24 Power/Other Input
AA2 Power/Other Input
AC21 Power/Other Input
AC20 Power/Other Input
AC24 Power/Other Input
AC23 Power/Other Input
AA20 Power/Other Input
AB22 Power/Other Input
U6 Power/Other Input
W4 Power/Other Input
Y3 Power/Other Input
A6 Power/Other Input
AD25 Power/Other Input
B3 Power/Other
C4 Power/Other
A2 Asynch GTL+ Output
F7 TAP Input
J6 Common Clock Input
E6 TAP Input
A10 Power/Other
A12 Power/Other
A14 Power/Other
A16 Power/Other
A18 Power/Other
Table 23. Alphabetical Pin Assignment
Signal Buffer
Pin Name Pin #
VCC A20 Power/Other
VCC A8 Power/Other
VCC AA10 Power/Other
VCC AA12 Power/Other
VCC AA14 Power/Other
VCC AA16 Power/Other
VCC AA18 Power/Other
VCC AA8 Power/Other
VCC AB11 Power/Other
VCC AB13 Power/Other
VCC AB15 Power/Other
VCC AB17 Power/Other
VCC AB19 Power/Other
VCC AB7 Power/Other
VCC AB9 Power/Other
VCC AC10 Power/Other
VCC AC12 Power/Other
VCC AC14 Power/Other
VCC AC16 Power/Other
VCC AC18 Power/Other
VCC AC8 Power/Other
VCC AD11 Power/Other
VCC AD13 Power/Other
VCC AD15 Power/Other
VCC AD17 Power/Other
VCC AD19 Power/Other
VCC AD7 Power/Other
VCC AD9 Power/Other
VCC AE10 Power/Other
VCC AE12 Power/Other
VCC AE14 Power/Other
VCC AE16 Power/Other
VCC AE18 Power/Other
VCC AE20 Power/Other
VCC AE6 Power/Other
VCC AE8 Power/Other
VCC AF11 Power/Other
VCC AF13 Power/Other
VCC AF15 Power/Other
VCC AF17 Power/Other
VCC AF19 Power/Other
Direction
Type
