Intel SL8J6 - Pentium 4 Processor Datasheet page 43

Table 23. Alphabetical Pin Assignment
Pin Name
D26#
D27#
D28#
D29#
D30#
D31#
D32#
D33#
D34#
D35#
D36#
D37#
D38#
D39#
D40#
D41#
D42#
D43#
D44#
D45#
D46#
D47#
D48#
D49#
D50#
D51#
D52#
D53#
D54#
D55#
D56#
D57#
D58#
D59#
D60#
D61#
D62#
D63#
DBI0#
DBI1#
DBI2#
Datasheet
Signal Buffer
Pin # Direction
Type
H24 Source Synch Input/Output
M21 Source Synch Input/Output
L22 Source Synch Input/Output
J24 Source Synch Input/Output
K23 Source Synch Input/Output
H25 Source Synch Input/Output
M23 Source Synch Input/Output
N22 Source Synch Input/Output
P21 Source Synch Input/Output
M24 Source Synch Input/Output
N23 Source Synch Input/Output
M26 Source Synch Input/Output
N26 Source Synch Input/Output
N25 Source Synch Input/Output
R21 Source Synch Input/Output
P24 Source Synch Input/Output
R25 Source Synch Input/Output
R24 Source Synch Input/Output
T26 Source Synch Input/Output
T25 Source Synch Input/Output
T22 Source Synch Input/Output
T23 Source Synch Input/Output
U26 Source Synch Input/Output
U24 Source Synch Input/Output
U23 Source Synch Input/Output
V25 Source Synch Input/Output
U21 Source Synch Input/Output
V22 Source Synch Input/Output
V24 Source Synch Input/Output
W26 Source Synch Input/Output
Y26 Source Synch Input/Output
W25 Source Synch Input/Output
Y23 Source Synch Input/Output
Y24 Source Synch Input/Output
Y21 Source Synch Input/Output
AA25 Source Synch Input/Output
AA22 Source Synch Input/Output
AA24 Source Synch Input/Output
E21 Source Synch Input/Output
G25 Source Synch Input/Output
P26 Source Synch Input/Output
Pin List and Signal Description
Table 23. Alphabetical Pin Assignment
Signal Buffer
Pin Name Pin #
DBI3# V21 Source Synch
DBR# AE25 Power/Other
DBSY# H5 Common Clock
DEFER# E2 Common Clock
DP0# J26 Common Clock
DP1# K25 Common Clock
DP2# K26 Common Clock
DP3# L25 Common Clock
DRDY# H2 Common Clock
DSTBN0# E22 Source Synch
DSTBN1# K22 Source Synch
DSTBN2# R22 Source Synch
DSTBN3# W22 Source Synch
DSTBP0# F21 Source Synch
DSTBP1# J23 Source Synch
DSTBP2# P23 Source Synch
DSTBP3# W23 Source Synch
FERR#/PBE# B6 Asynch AGL+
GTLREF AA21 Power/Other
GTLREF AA6 Power/Other
GTLREF F20 Power/Other
GTLREF F6 Power/Other
HIT# F3 Common Clock
HITM# E3 Common Clock
IERR# AC3 Asynch GTL+
IGNNE# B2 Asynch GTL+
INIT# W5 Asynch GTL+
ITP_CLK0 AC26 TAP
ITP_CLK1 AD26 TAP
LINT0 D1 Asynch GTL+
LINT1 E5 Asynch GTL+
LOCK# G4 Common Clock
MCERR# V6 Common Clock
OPTIMIZED/
AE26 Power/Other
COMPAT#
PROCHOT# C3 Asynch GTL+
PWRGOOD AB23 Power/Other
REQ0# J1 Source Synch
REQ1# K5 Source Synch
REQ2# J4 Source Synch
REQ3# J3 Source Synch
REQ4# H3 Source Synch
Direction
Type
Input/Output
Output
Input/Output
Input
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Output
Input
Input
Input
Input
Input/Output
Input/Output
Output
Input
Input
Input
Input
Input
Input
Input/Output
Input/Output
Input
Input/Output
Input
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
43
