Step 7 M-Series Cabinets (continued)
Cabinet Configuration Chart for AlphaServer ES40 (8U) with StorageWorks Shelves (4U)
Cabinet
Rack Kit
BA61R-RM
H9A10-MC/MD
1
BA61R-RM
H9A15-MC/MD
4
NOTES:
1.
Contact CustomSystems for cabinet configurations with four AlphaServer ES40 systems installed in H9C10-MC/MD cabinet.
2.
Japan only – 240V cabinet required when using universal shelves
3.
When using a combination of BA356 and DS-SL13R shelves in the same cabinet, do not remove the top fan (only remove fan when
using DS-SL13R shelves exclusively)
4.
Installation of one AlphaServer ES40 system in an H9A15 cabinet requires the mandatory selection of a ballast kit.
5.
When adding the 5th system drawer, replace H7600-AA or -DB power controller with H7602-EA or -DB power controller. When replacing
H7600 controllers, replace all associated power cords; order BN35S-4E power cords for H7602-EA and H7602–DB power controllers.
M-Series Cabinets
DA-10392
North America — Version 57 — March 18, 2003
Cabinet
Cabinet
Extender
Height/Space
H9C10-TE
67-inches/34U
H9C15-TE
79-inches/41U
Required selection of one cabinet
Two H7600-xx power distribution units are standard in the M-Series cabinet
For cabinet configurations that require a third power distribution unit (H7600-xx),
contact CustomSystems at 1-800-282-6672.
67-inch cabinet with 59.5-inch or 34U of usable vertical space, 120V dual-24A
controller, each with 10 NEMA 5-15R outlets, input power plug NEMA L5-30P,
Americas, Asia Pacific; includes rear door and top fan tray
67-inch cabinet with 59.5-inch or 34U of usable vertical space, 240V dual-16A
controller, each with 12 IEC C13 outlets, input power plug IEC 309, 16A, Europe;
includes rear door and top fan tray
79-inch cabinet with 71.7-inch or 41U of usable vertical space, 120V dual-24A
controller, each with 10 NEMA 5-15R outlets, input power plug NEMA L5-30P,
Americas, Asia Pacific; includes rear door and top fan tray
79-inch cabinet with 71.7-inch or 41U of usable vertical space, 240V dual-16A
controller, each with 12 IEC C13 outlets, input power plug IEC 309, 16A, Europe;
includes rear door and top fan tray
Compaq AlphaStation ES40
Systems
BA356 Shelves DS-SL13R 120V
1
6
2
6
3
2
4
0
1
1
6
2
6
3
6
4
2
5
0
5
Compaq AlphaServer ES40
BA356/
Shelves
DS-SL13R
2
BA356
8
6
5
6
2
4
0
0
8
6
5
6
2
6
0
2
0
0
3
DS-SL13R
4
1
0
0
5
2
0
0
0
H9A10-MC
H9A10-MD
H9A15-MC
H9A15-MD
9
