Compaq DA-64CAA-DA - AlphaServer - ES40 Model 2 Specification page 7

QuickSpecs
Options
Step 5 Disk Drive Cage or StorageWorks Shelf Mandatory (continued)
Step 5c StorageWorks Model 4314R and Model 4354R Universal Drive Shelves
StorageWorks Model 4314T Standalone
Enclosure for Universal Drives
DA-10392 North America — Version 57 — March 18, 2003
StorageWorks Model 4314R and 4354R Ultra2 SCSI (LVD) single-bus and split-
bus Universal drive shelves; refer to StorageWorks Enclosure 4300 Family
QuickSpecs when configuring shelves. When selecting a DS-SL13R-xx split-bus
shelf, order two UltraSCSI adapters. Model 43xx shelves are compatible with
Wide Ultra2 (LVD) adapters only.
BN38C-05 cable is required per channel if the connection is not VHDCI/VHDCI.
DS-SL13R shelves include one 12-foot VHDCI/VHDCI SCSI cable.
Note that the depth of a DS-SL13R-xx shelf does not allow front and rear
mounting.
StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount
shelf, includes one power supply, U.S. (190209-0011)
StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount
shelf, includes one power supply, Japan (190209-291)
StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount
shelf, includes two redundant power supplies, U.S. (190211-0011)
StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount
shelf, includes two redundant power supplies, Japan (190211-291)
To add additional power supply for single-bus Universal shelf, U.S. (212980-B21)
To add additional power supply for single-bus Universal shelf, International
(119826-B31)
Model 4314T Ultra3 SCSI, single-bus tower enclosure, U.S. (190210-001)
Model 4314T Ultra3 SCSI, single-bus tower enclosure, International (190210-B31)
Model 4314T Ultra3 SCSI, single-bus tower enclosure, Japan (190210-291)
Compaq AlphaServer ES40
Compaq AlphaStation ES40
DS-SL13R-AA
DS-SL13R-AJ
DS-SL13R-BA
DS-SL13R-BJ
DS-SE2UP-AA
DS-SE2UP-AI
DS-SL13T-AA
DS-SL13T-AB
DS-SL13T-AJ
7
