Compaq DA-64CAA-DA - AlphaServer - ES40 Model 2 Specification page 23

QuickSpecs
Options
Step 11 Storage Devices Optional (continued)
Step 11a Tape Devices (continued)
5U Rackmount Tape Drive Enclosure
Step 11b – Network Storage Routers
Network Storage Routers
DA-10392 North America — Version 57 — March 18, 2003
5U LVD Rackmount Tape Drive Enclosure for use in H9Axx M-Series Cabinets, 0
drives, carbon black
Rackmount Kit for H9Axx M-Series Cabinets, carbon black required for mounting 5U
Rackmount Tape Drive Enclosure in M-Series Cabinet
NOTE: The 5U Rackmount Tape Enclosure supports four full-height removable devices;
select up to four DLT or SDLT devices with 5U Rackmount Tape Enclosure
(274339-B21) or choose one of the preconfigured configurations listed below.
DLT8000 40/80-GB tape drive
SDLT 110/220-GB tape drive
SDLT 160/320-GB tape drive, carbon black
Preconfigured configurations
SDLT 110/220-GB Tape Array III, 5U rackmount kit, carbon black
DLT 40/80-GB Tape Array III, 5U rackmount kit, carbon black
DLT Tape Array III Model 0 enclosure, U.S.
Same as above, International
Same as above, Japan
NOTE: The following Network Storage Routers (Tru64 UNIX) are supported with MSL5000 and ESL9000 tape
libraries
NSR M2402 Two Fibre Channel x 4 HVD FC to SCSI Data Router, Tru64 UNIX and
OpenVMS (262654-B21)
NSR M2402 Two Fibre Channel x 4 LVD FC to SCSI Data Router, Tru64 UNIX and
OpenVMS (262653-B21)
NSR e1200 One Fibre Channel x 2 LVD FC to SCSI Data Router, Tru64 UNIX and
OpenVMS, carbon black (262672-B21)
NSR e2400 Two Fibre Channel x 4 LVD FC to SCSI Data Router with card cage, Tru64
UNIX and OpenVMS, carbon black (262665-B21)
NSR e2400 Two Fibre Channel x 4 LVD FC to SCSI Data Router without card cage,
Tru64 UNIX and OpenVMS, carbon black (262664-B21)
NSR N1200 One Fibre Channel x 2 LVD FC to SCSI Data Router, Tru64 UNIX and
OpenVMS, supports tape drives and tape libraries (280823-B21)
Compaq AlphaServer ES40
Compaq AlphaStation ES40
274339-B21
254795-001
146196-B22
192106-B25
257319-B21
274336-B21
274337-B21
168047-001
168047-B31
168047-291
3R-A3741-AA
3R-A3740-AA
3R-A3746-AA
3R-A3935-AA
3R-A3745-AA
3R-A3747-AA
23
