Configuring Information - Compaq DA-64CAA-DA - AlphaServer - ES40 Model 2 Specification

QuickSpecs
Options
Step 8 Networking Adapters/Controllers (continued)
Step 8c Multi-use Cables
Ethernet, FDDI, ATM
Multimode fiber optic (MMF) 62.5/125um duplex cable, with SC-to-ST
connectors.
–xx = available lengths: (2E, 4E, 01, 03, 10, 20, 30) for 2.4, 4.5, 1, 3, 10, 20,
30 meters
Multimode fiber optic (MMF) 62.5/125um duplex cable, with SC-to-SC
connectors.
-xx = available lengths: (2E, 4E, 01, 03, 10, 20, 30) for 2.4, 4.5, 1, 3, 10, 20,
0 meters
Category 5e (4-Unshielded Twisted Pairs / UTP) straight-through cable with
RJ45-to-RJ45 connectors for system to switch, repeater, or hub connectivity.
-xx = available lengths: (0B, 0E, 01, 03, 04, 07) for 0.2, 0.5, 1, 3, 4, 7 meters
Category 5e (4-Twisted Pairs, Screened/ ScTP) straight-through cable with
RJ45-to-RJ45 connectors for system to switch, repeater, or hub connectivity.
-xx = available lengths: (0E, 01, 03, 04, 07) for 0.5, 1, 3, 4, 7 meters
Category 5e (4-Unshielded Twisted Pairs / UTP) Xover cable with RJ45-to-
RJ45 connectors for system to switch, repeater, or hub connectivity.
-xx = available lengths: (0E, 01, 03, 04, 07) for 0.5, 1, 3, 4, 7 meters
Category 5e (4-Twisted Pairs, Screened / ScTP) Xover cable with RJ45-to-
RJ45 connectors for system to switch, repeater, or hub connectivity.
-xx = available lengths: (0E, 01, 03, 04, 07) for 0.5, 1, 3, 4, 7 meters
Step 9 MEMORY CHANNEL Optional
NOTE: When using MEMORY CHANNEL, refer to the TruCluster QuickSpecs for configuration guidelines and restrictions:
http://www.compaq.com/products/quickspecs/Division/10657.html
The MEMORY CHANNEL controller, CCMAB-AA, must be revision C1 or later.
Tru64 UNIX Systems
(V5.0A and later)
Tru64 UNIX Systems (V4.0F)
OpenVMS Systems

Configuring Information

DA-10392 North America — Version 57 — March 18, 2003
Each system node in the cluster requires a TruCluster software license
(QL-6BRAE-AA)
Requires a minimum of Tru64 UNIX V4.0F with TruCluster V1.6 or later
Each system node in the cluster requires a TruCluster Production Server
(QB-3RLAE-AA) or TruCluster MEMORY CHANNEL software license
(QB-4ZCAE-AA)
TruCluster MEMORY CHANNEL license (QB-4ZCAG-AA), normally used for high
performance technical computing applications, not required if systems include a TruCluster
Production Server license (QB-3RLAE-AA)
OpenVMS V7.2-2 or later and OpenVMS Cluster license (QL-MUZAE-AA) are required
Up to two PCI-to-System Area Network adapters (CCMAB-AA) are supported in a single
system.
Two-node clusters can be configured by ordering a CCMAB-AA for each node and one
BN39B-04 or BN39B-10 cable; cable connects directly to CCMAB-AA in each node
For a two-node cluster that will not be rebooted when adding additional members, order
one CCMAB-AA adapter and one BN39B-04 or BN39B-10 cable for each node and one
CCMHB-AA hub for the cluster
Two-node clusters can also be configured by ordering two CCMAB-AA adapters for each
node and two BN39B-04 or BN39B-10 cables; cables connect directly to CCMAB-AA in
each node.
For three or four node clusters, order one CCMAB-AA adapter and one BN39B-04 or
BN39B-10 cable for each node, and one CCMHB-AA hub for the cluster If two CCMAB-
AAs are configured in each system, a second CCMHB-AA is required.
CCMHB-AA includes four CCMLB-AA line cards and supports up to four nodes; expansion
up to eight system nodes can be achieved by adding up to four CCMLB-AA line cards.
Compaq AlphaServer ES40
Compaq AlphaStation ES40
Maximum # Supported
Tru64 UNIX OpenVMS Linux
BN34A-xx
BN34B-xx
BN25G-xx
BN26M-xx
BN24Q-xx
BN28Q-xx
13
