Compaq DA-64CAA-DA - AlphaServer - ES40 Model 2 Specification page 27

QuickSpecs
Options
Step 13 Monitors Optional
Graphics monitors other than those listed can be used if compatible with SVGA graphics ordered with system
A video cable, 6-foot/1.8-meter length, is included with all variants of monitors.
Video extension cable required if monitor is located more than 1 meter from server
Monitors will ship with, but not be integrated with systems.
Carbon/Silver Monitors
Carbon/Silver Flat Panel Monitors
Video Extension Cable
Monitor Power Cords
DA-10392 North America — Version 57 — March 18, 2003
V7550 17-inch (16-inch viewable image size) flat-faced shadow mask color monitor,
two-tone (carbon/silver), 0.25mm dot pitch, VGA to 1024 x 768 @85 Hz, MPRII/TCO
99/Energy Star Compliant, Northern Hemisphere with NA power cord, VGA cable
Same as above, with Euro power cord
Same as above, APD, no power cord
Same as above, with PRC power cord, CCIB
Same as above, Southern Hemisphere, with Australia/New Zealand power cord
P930 19-inch (18-inch viewable image size) auto-scanning color monitor, Diamondtron
NF, 0.24-mm aperture grille pitch, VGA to 1600 x 1200 @85 Hz, MPRII/TCO 99/Energy
Star Compliant, Northern Hemisphere with NA power cord, VGA cable,
Same as above, with Euro power cord
Same as above, Taiwan, with NA power cord
Same as above, with PRC power cord, CCIB
Same as above, Southern Hemisphere, 0.25 to 0.27 mm aperture grille pitch, with
Australia/New Zealand power cord
P1130 21-inch (19.8-inch viewable image size) FD Trinitron auto-scanning color
monitor, Diamondtron NF, 0.24-mm aperture grille pitch, VGA to 1792 x 1344 @85Hz,
dual video input, USB Hub, MPRII/TCO 99/Energy Star Compliant, Northern
Hemisphere with NA power cord, VGA cable
Same as above, with Euro power cord
Same as above, Taiwan, no power cord
Same as above, with PRC power cord, CCIB
Same as above, Southern Hemisphere, with Australia/New Zealand power cord
TFT1825, 18-inch (18-inch viewable image size) TFT flat panel monitor, 0.28mm pixel
pitch, 1600 x 1200 @60Hz, multi-mode support, MPRII/TCO99/Energy Star compliant,
one VGA, one DVI-I input connector. NA power cord, VGA and DVI-I cables
TFT1520, 15-inch (15-inch viewable image size) TFT flat panel monitor, 0.297 mm pixel
pitch, 1024 x 768 @75 Hz, multi-mode support, MPRII/TCO99/Energy Star compliant,
two video input connectors (one VGA and one DVI-I), NA power cord, VGA and DVI-I
cables
6-foot/1.8-meter video extension cable optional
North America, 120V, 75-inch
Australia, New Zealand, 2.5-meter (103541-011)
Central Europe, 2.5-meter
Denmark, 2.5-meter (103541-481)
Egypt, India, South Africa, 2.5-meter (103541-AR1)
Israel, 2.5-meter
Italy, 2.5-meter (103541-461)
Japan, 2.5-meter, Dentori approved
Switzerland, 2.5-meter (103541-511)
UK, Ireland, 2.5-meter
Compaq AlphaServer ES40
Compaq AlphaStation ES40
3R-A4002-AA
3R-A4201-AA
3R-A4202-AA
3R-A4446-AA
3R-A4203-AA
3R-A4215-AA
3R-A4391-AA
3R-A4392-AA
3R-A4394-AA
3R-A4393-AA
3R-A4216-AA
3R-A4396-AA
3R-A4397-AA
3R-A4400-AA
3R-A4398-AA
3R-A4292-AA
3R-A4249-AA
BN39C-02
BN26J-1K
BN19H-2E
BN19C-2E
BN19K-2E
BN19S-2E
BN18L-2E
BN35M-02
3X-BN46F-02
BN19E-2E
BN19A-2E
27
