QuickSpecs
Systems/Options
Step 2 Additional CPU Modules Optional
One CPU included, three additional CPUs are supported
From:
EV67 667-MHz CPU
EV6 500-MHz CPU

Step 3 Memory Optional

Systems include one memory option
Model 1 systems supports four memory options (total of 16 DIMMs)
Model 2 systems support eight memory options (total of 32 DIMMs see Note below)
Memory performance considerations: Interleaved operations reduce the average latency and increase the memory throughput over non-
interleaved operations. With one memory option (4 DIMMs) installed, memory interleaving will not occur. With two identical memory
options (8 DIMMs) installed, memory read-write operations are two-way interleaved. With four identical memory options (16 DIMMs)
installed, memory read-write operations are four-way interleaved, maximizing memory through-put
DA-10392 North America — Version 57 — March 18, 2003
SMP upgrade, includes one 67/667-MHz CPU with 8-MB cache and Tru64 UNIX
SMP license
SMP upgrade, includes one 67/667-MHz CPU with 8-MB cache and OpenVMS
SMP license
SMP upgrade, includes one 68/833-MHz CPU with 8-MB cache and Tru64 UNIX
SMP license
SMP upgrade, includes one 68/833-MHz CPU with 8-MB cache and OpenVMS
SMP license
To:
EV68 833-MHz CPU
Upgrade console firmware to V5.9-24 as minimum revision
Upgrade system hardware with EV68 CPUs
Ensure all system firmware matches console version V5.9-24
EV68 833-MHz CPU
Upgrade console firmware to V5.9-24 as minimum revision
Upgrade system hardware with EV68 CPUs
Re-install V5.9-24 console firmware
Ensure all system firmware matches console version V5.9-24
512-MB memory option (4 x 128-MB DIMMs)
1-GB memory option (4 x 256-MB DIMMs)
2-GB memory option (4 x 512-MB DIMMs)
4-GB memory option (4 x 1024-MB DIMMs)
NOTE: ES40 configurations that require maximum N+1 power (three power supplies)
are restricted to a maximum of 24-GB of mixed memory (sixteen 1-GB DIMMs
and sixteen 512-MB DIMMs). If N+1 maximum power is not required, 32-GB of
memory is supported.
Compaq AlphaServer ES40
Compaq AlphaStation ES40
KN610-BB
KN610-BC
KN610-CB
KN610-CC
MS610-CA
MS610-DA
MS610-EA
MS610-FA
4
