QuickSpecs
Options
Step 11 Storage Devices Optional (continued)
Step 11c – External Storage Solutions/Controllers (continued)
Fibre Channel Controller
StorageWorks Disk Array Family
RA3000 RAID Array
Step 11d – Fibre Channel Options
Fibre Channel Disk Drives
Fibre Channel Hubs
Fibre Channel Data Routers
Fibre Channel Switches
DA-10392 North America — Version 57 — March 18, 2003
Fibre Channel Controller (HSG80), includes 256-MB cache; requires following firmware:
8.6-4F ACS FW (222318-B22, QB-6BUAA-SD), one per controller
8.6-4S ACS FW (222364-B22 QB-6ENAA-SC), one per controller
8.6-4P ACS FW (222316-B22, QB-6CAAA-SD), one per controller
Requires Tru64 UNIX software: 222320-B23, QB-65RAB-SE, one per controller
Requires OpenVMS software: 222321-B22, QB-65RAC-SD, one per controller
Additional 256-MB cache for HSG80 (380674-B21)
Single cache battery, one per HSG80 controller (135823-B21)
Model 2200 controller shelf for HSG80 controller (135820-B21)
NOTE: The HP StorageWorks Disk Array Family, specifically the XP128 and XP1024,
are supported on AlphaServer ES40 systems. For product and ordering
information, refer to the following Web pages:
http://www.hp.com/products1/storage/products/disk_arrays/highend/xp1024/
index.html
http://www.hp.com/products1/storage/products/disk_arrays/highend/xp128/
index.html
The following part numbers have been assigned for reference purposes only:
3R-A4417-AA A7876A
3R-A4418-AA A7906A
RAID Array 3000 (HSZ22) storage array is supported on AlphaServer ES40 systems
(Tru64 UNIX V4.0F, V5.0A or higher and OpenVMS V7.x); supports KZPBA-CB
adapter, minimum console V5.8
For ordering information see:
http://www.compaq.com/products/StorageWorks/raidstorage/RA3000ped_config.html
NOTE: This website is available in English only.
The following hubs, data routers, switches, and cables are used in Fibre Channel configurations using the
DS-KGPSA-xx adapter.
36-GB 10K rpm dual-port 2-Gb/sec FC-AL 1-inch (25.4 mm) drive (238590-B21)
72-GB 10K rpm dual-port 2-Gb/sec FC-AL 1-inch (25.4 mm) drive (238921-B21)
36-GB 15K rpm dual-port 2-Gb/sec FC-AL 1-inch (25.4 mm) drive (236205-B21)
Fibre Channel 7-port Storage Hub, International (Tru64 UNIX only) (234453-B31)
Fibre Channel 7-port Storage Hub, Japan (Tru64 UNIX only) (234453-291)
1 Fibre Channel x 2 HVD data router (163082-B21)
1 Fibre Channel x 2 LVD data router (163083-B21)
2 x 4 LVD Fiber Channel to SCSI Network Storage Router (262653-B21)
2 x 4 HVD Fiber Channel to SCSI Network Storage Router (262654-B21)
Fibre Channel 2-Gb 8-port SAN switch (258707-B21)
Fibre Channel 2-Gb 16-port SAN switch (283056-B21)
Fibre Channel SAN 2-Gb switch – 16-port (287055-B2)
- Requires Tru64 UNIX V5.1A Patch Kit: T64V51AB01AS0001-20020116.tar
- Requires Tru64 UNIX V5.1 Patch Kit: T64V51AS0003-20010521.tar
Fibre Channel 2-Gb 64-port Core Switch (254508-B21)
Compaq AlphaServer ES40
Compaq AlphaStation ES40
XP128 Disk Array Control Frame
XP1024 Disk Array Control Frame
DS-HSG80-BK
DS-HSDIM-AC
DS-SE2CS-CB
DS-SE2ZS-C8
3R-A3239-AA
3R-A3260-AA
3R-A3210-AA
DS-SWXHB-17
DS-SWXHB-J7
3R-A2673-AA
3R-A2774-AA
3R-A3740-AA
3R-A3741-AA
DS-DSGGD-AC
DS-DSGGD-AD
DS-DSGGD-BA
DS-DSGGE-AB
