QuickSpecs
Compaq iPAQ Desktop
Overview
A t A G l a n c e
The Compaq iPAQ Desktop is a sleek,
affordable, easy to deploy and manage
business PC—ideal for mainstream
computing, Internet / intranet access,
and Windows 2000 deployments.
There are two iPAQ™ Desktop
versions. The Compaq iPAQ Desktop
with Legacy Ports has traditional
legacy ports (parallel, serial, and PS/2)
for existing peripherals, running
Windows 2000, 98, or NT4. The
Compaq iPAQ Desktop Legacy-Free
features Windows 2000 or ME and six
USB ports for the new wave of USB
peripherals.
Order iPAQ directly from Compaq at
www.compaq.com/products/desktops
iPAQ Desktops deliver ease of
deployment, support, and usability by
eliminating ISA/PCI slots and focusing
on USB with Windows 2000 or
Windows ME.
Compaq Intelligent Manageability
provides solutions for remote cloning,
deployment, installation, configuration,
and backup/restore; single-click
scheduling for all management tasks;
and powerful brokering agents to
handle requests automatically and
communicate status to the
management console (Intelligent
Manageability is not supported under
Windows ME).
Innovative Compaq MultiBay
technology enables hot-swapping of
slimline CD-ROM, DVD-ROM,
SuperDisk LS-120 drive, Zip 250 drive,
and hard drive without the need to
reboot. The breakthrough industrial
design features a sleek, small footprint,
leaving the user more workspace.
Protected by Compaq Services,
including a limited one-year warranty
for parts and onsite labor — Certain
restrictions and exclusions apply.
Consult the Compaq Customer
Support Center for details.
DA-10832
North America — Version 8 — September 14, 2001
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DA-10832 and is the answer not in the manual?

Questions and answers

Summary of Contents for Compaq DA-10832

  • Page 1 QuickSpecs Compaq iPAQ Desktop Overview A t A G l a n c e The Compaq iPAQ Desktop is a sleek, affordable, easy to deploy and manage business PC—ideal for mainstream computing, Internet / intranet access, and Windows 2000 deployments.
  • Page 2 Note: * End-user must make a one-time selection between Windows 2000 and Windows NT Workstation. If end-user desires rejected product after selection is made, end-user must purchase and acquire rejected product(s) separately. DA-10832 North America — Version 8 — September 14, 2001 470018-137 470018-140 470018-156 470018-160 470018-162 470018-163 470018-164 Compaq iPAQ Desktop...
  • Page 3: Standard Features

    B o o t S u p p o r t Network Service Boot (PXE) – with appropriate remote application DA-10832 North America — Version 8 — September 14, 2001 Compaq iPAQ Desktop 128-MB SDRAM (PC 133) 512-MB SDRAM 64-MB SDRAM (PC 133) 512-MB SDRAM Smart II Ultra ATA 100 –...
  • Page 4 I n i t i a l C o n f i g u r a t i o n a n d Replicated Setup D e p l o y m e n t Compaq OS Restore CD Asset Tag A s s e t C o n t r o l DIMM Serial Presence Detect Hard drive serial number, model &...
  • Page 5 Microsoft Windows ME (iPAQ Desktop Legacy Free only) S e r v i c e a n d S u p p o r t One-year parts and on-site labor standard DA-10832 North America — Version 8 — September 14, 2001 Compaq iPAQ Desktop...
  • Page 6: Security Devices

    ACS21 Altec-Lansing Speakers Removable Storage MultiBay SuperDisk LS-120 Drive MultiBay 250 Zip Drive External USB 1.44MB Floppy Drive Security Devices Compaq Security Lock Legacy Module Other DA-10832 North America — Version 8 — September 14, 2001 Compaq iPAQ Desktop 174225-B21...
  • Page 7 Slot 1 Standard 64 MB 64 MB 512 MB 256 MB Following are memory options available from Compaq: 64-MB SDRAM Memory Upgrade 128-MB SDRAM Memory Upgrade 256-MB SDRAM Memory Upgrade DA-10832 North America — Version 8 — September 14, 2001...
  • Page 8 Slot 1 Standard 128 MB 128 MB 512 MB 256 MB Following are memory options available from Compaq: 64-MB SDRAM Memory Upgrade 128-MB SDRAM Memory Upgrade 256-MB SDRAM Memory Upgrade DA-10832 North America — Version 8 — September 14, 2001...
  • Page 9 North America — Version 8 — September 14, 2001 R I V E U P P O R T Quantity Supported Position Supported MultiBay MultiBay MultiBay MultiBay MultiBay Internal Hard Drive MultiBay Compaq iPAQ Desktop Controller Ultra ATA 100 (embedded)
  • Page 10: Technical Specifications

    Mechanical Environmental DA-10832 North America — Version 8 — September 14, 2001 Compaq iPAQ Desktop 13.8 x 5.4 x 10.43 in/34.9 x 13.8 x 26.4 cm 10.3lbs/4.68kg (without MultiBay device, keyboard, or mouse) 90 to 132 VAC/180 to 264 VAC...
  • Page 11 Technical Specifications Compaq 2-Button Scroll Mouse Environmental Electrical Mechanical Scroll Wheel Regulatory Approvals DA-10832 North America — Version 8 — September 14, 2001 Compaq iPAQ Desktop Operating Temperature 50 to 122 F/10 to 50 C Non-operating Temperature –22 to 140 F/–30 to 60 C...
  • Page 12 Line Draw Text Color Expansion Basic Video Color Conversion and Scaling Triangle Setup Engine Microsoft Windows 95 Microsoft Windows 98 Microsoft Windows NT 4.0 Microsoft Windows 2000 Microsoft Windows ME Dynamic main memory allocation 1280 x 1024 Compaq iPAQ Desktop 16.7M...
  • Page 13 Internal Audio Power Amp Rating Number of Fixed Equalization Stages Speaker (Internal) DA-10832 North America — Version 8 — September 14, 2001 Compaq iPAQ Desktop 128 WaveTable Synthesizer Sound Blaster Sound Blaster Pro Full DOS Game Compatibility Microphone in (10 Kohm)
  • Page 14 Yes, (PME# and WAKE signals) - no cable required on 810 or 820 chipset platforms Yes, alert on LAN (transmit functionality only) requires management console software, such as Compaq Insight Manager. It also requires alert utilities for the management console, proxy client software, and client configuration software.
  • Page 15 Average Full-Stroke Rotational Speed 7200 rpm Logical Blocks 39,102,336 Operating Temperature 41 to 131 F/5 to 55 C Compaq iPAQ Desktop 1.2 ms (2.7 ms quiet seek) 8 ms (14.3 ms quiet seek) 18.0 ms (24.1 ms quiet seek) 19,485...
  • Page 16 DA-10832 North America — Version 8 — September 14, 2001 Compaq iPAQ Desktop CD-ROM (Mode 1, 2 and 3), CD-XA ready (Mode 2, Form 1 and 2), CD-I ready (Mode 2, Form 1 and 2), CD-R (read only), CD Plus, Photo CD (Single and Multi- session), CD-Extra, Video CD, CD-WO (fixed packets only), CD-Bridge 12.7 mm MultiBay...
  • Page 17 Stop Time Operating System Support Windows 98/98SE, Windows 2000, Windows Millennium, Windows NT 4.0 Option Kit Contents DA-10832 North America — Version 8 — September 14, 2001 Compaq iPAQ Desktop 12.7 mm MultiBay 0.59 in/0.39 cm 12 cm/8 cm 1.2 mm 0.74 µm...
  • Page 18 Data Transfer Rate (typical, including settling) Operating Conditions Operating Systems Kit Contents DA-10832 North America — Version 8 — September 14, 2001 Compaq iPAQ Desktop IDE (ATAPI) Zip Disk 250 MB & 100 MB 29 ms (average) 2941 rpm 250 MB Cartridge 2.4 Mb/s...
  • Page 19 Windows NT 4.0 and Windows 2000. Use the SuperDisk LS-120 Drive Option Support Diskette (included in option kit) with earlier releases of Windows 95 and NT 3.51. Option Kit Contents SuperDisk LS-120 Drive, SuperDisk Media, Documentation Compaq iPAQ Desktop 51 to 92 1736 20 ms 70 ms 41.67...
  • Page 20 Technical Specifications USB 1.44 External Floppy Drive rate Compaq PCs use genuine Microsoft Windows www.Microsoft.com\piracy\howtotell Microsoft and Windows are trademarks of Microsoft Corporation in the U.S. and other countries. DA-10832 North America — Version 8 — September 14, 2001 Dimensions (HxWxD) 0.7 x 4.0 x 5.5 in/17.6 x 103 x 140 mm...
