Compaq DA-64CAA-DA - AlphaServer - ES40 Model 2 Specification page 6

QuickSpecs
Options
Step 5 Disk Drive Cage or StorageWorks Shelf Mandatory
Tower enclosure supports one system and two disk drive cages
Pedestal enclosure supports one system and two disk drive cages, two Universal 42xx/43xx StorageWorks shelves or three BA36R
StorageWorks shelves
M-Series cabinets support five systems each with two disk drive cages and up to six StorageWorks shelves
Step 5a Disk Drive Cage Requires selection of system disk drive
Disk Drive Cages
System Disk Drives
(Supported in Disk Drive Cage and
Universal StorageWorks Shelves)
Step 5b StorageWorks BA36R Shelf Requires selection of UltraSCSI adapter and SCSI cable (Step 10) and system disk drive
StorageWorks Shelf supports seven 3.5-inch x 1.6-inch hard disk drives; with addition of redundant power supply, only six drives are
supported
StorageWorks shelf kits are mounted back-to-back in pedestals and cabinets
System Disk Drive
(Supported in StorageWorks
BA36R Shelf)
DA-10392 North America — Version 57 — March 18, 2003
6-bay disk drive cage with cable for use with 1-inch Universal drives – requires
mandatory selection of UltraSCSI adapter and SCSI cable (Step 10) per disk drive cage
6-bay disk drive cage with embedded Ultra2 LVD adapter; supports internal SCSI
1-inch Universal drives or tapes only
OpenVMS V7.2-2 requires OpenVMS Tima Kit located at:
- http://ftp.support.compaq.com/patches/.new/openvms.shtml
Tru64 UNIX V4.0F requires Patch Kit 2 (BL13):
- DUV40FAS0002-19991116.tar
NOTE: See AlphaServer ES40 Configuration Chart for Storage Adapters in Step 10.
18.2-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive
36.4-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive
36.4-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive
72.8-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive
72.8-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive
146-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive
StorageWorks UltraSCSI single-bus shelf kit
StorageWorks UltraSCSI split-bus shelf kit;
NOTE: When ordering a split-bus shelf that will be mounted in a Pedestal Enclosure,
order one BN37A-03 cable for KZPCM-DA adapter, BN37A-03 cable for
3X-DEPVZ-AA combo adapter, or one BN38C-03 for 3X-KZPCA-AA or
KZPBA-CA adapter.
3-meter SCSI cable
36.4-GB Wide UltraSCSI 10,000 rpm disk drive
Compaq AlphaServer ES40
Compaq AlphaStation ES40
BA610-6D
BA610-6E
3R-A3848-AA
3R-A3838-AA
3R-A3849-AA
3R-A3839-AA
3R-A3851-AA
3R-A3841-AA
BA36R-RC
BA36R-RD
BN37A-03
DS-RZ1FC-VW
6
