Compaq DA-64CAA-DA - AlphaServer - ES40 Model 2 Specification page 26

QuickSpecs
Options
Step 11 Storage Devices Optional (continued)
Step 11d – Fibre Channel Options (continued)
McData 64-port Fibre Channel SAN
Director Class Switches
Fibre Channel Cables
Step 12 Graphics Adapters Optional
RAID Configuration Utility is accessible via console port; optional graphics capability is available
Select graphics adapter, monitor, and country-specific keyboard for Tru64 UNIX and OpenVMS systems if
required
2D Graphics 3Dlabs Oxygen VX1 32-MB PCI 2D graphics accelerator
NOTE: Only one 3X-KZPEA-DB adapter is allowed with
SN-PBXGF-AB adapter.
PCI (32-bit, 33-MHz) multi-function (single-port 10/100 Ethernet
UTP/RJ45, Ultra2 LVD SCSI, and 2D graphics) adapter
NOTE: No support for multi-head graphics.
OpenVMS V7.2-2 requires OpenVMS Tima Kit located at:
- http://ftp.support.compaq.com/patches/.new/openvms.shtml
Tru64 UNIX V5.1 requires Patch Kit 3:
- T64V51AS0003-20010413.tar
Tru64 UNIX V4.0F with NHD2 TruCluster V5.1 support restricted to
non-shared buses
Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45
3D Graphics PowerStorm 300 3D multi-head graphics accelerator with 15-MB
frame buffer memory and 16-MB texture memory
NOTE: Graphics controllers must be the same type (PowerStorm);
no mixing.
NOTE: If using SN-PBXGD-AD graphics adapter on the same PCI
bus with the 3X-KZPEA-DB adapter, the SN-PBXGD-AD
must be at minimum revision C06.
PowerStorm 350 3D multi-head graphics accelerator with 30-MB
frame buffer memory and 32-MB texture memory
NOTE: If using SN-PBXGD-AE graphics adapter on the same PCI
bus with the 3X-KZPEA-DB adapter, the SN-PBXGD-AE
must be at minimum revision B05 or A03.
NOTE: PowerStorm 300 and PowerStorm 350 adapters require the following:
OpenVMS V7.2-2 (minimum version required) requires OpenVMS Tima Kits located at:
http://ftp.support.compaq.com/patches/.new/openvms.shtml
Tru64 UNIX V4.0F (minimum version required) requires Patch Kit 1 with Environmental Patch
PowerStorm 300 and PowerStorm 350 adapters can be combined, provided the system maximum is not exceeded.
DA-10392 North America — Version 57 — March 18, 2003
SAN Director 64 (1 GB) 32 ports, base model
SAN Director 2 Gb, 64 ports (286809-B21)
SAN Edge Switch 2 Gb, 32 ports (286810-B21)
SAN Edge Switch 2-Gb, 16 ports (286811-B21)
NOTE: Connection for, or between, 1-Gb and/or 2-Gb SAN switches requires different
cables. Refer to the Switches, Hubs, and Interconnects QuickSpecs at:
http://www.compaq.com/products/quickspecs/North_America/10490.html
NOTE: The following LC-SC connector cables support connectivity between 1-Gb and
2-Gb devices.
2-meter LC-SC multi-mode Fibre Channel cable (221691-B21)
5-meter LC-SC multi-mode Fibre Channel cable (221691-B22)
15-meter LC-SC multi-mode Fibre Channel cable (221691-B23)
30-meter LC-SC multi-mode Fibre Channel cable (221691-B26)
50-meter LC-SC multi-mode Fibre Channel cable (221691-B27)
NOTE: The following LC-LC connector cables support connectivity between 2-Gb and
2-Gb devices.
2-meter LC-LC multi-mode Fibre Channel cable (221692-B21)
Compaq AlphaServer ES40
Compaq AlphaStation ES40
Maximum # Supported
Tru64 UNIX OpenVMS
1 1
1 1
Requires
Slot 0
cables.
8 4
8 4
DS-DMGGD-AA
DS-DMGGD-BA
DS-DMGGE-BC
DS-DMGGE-BB
3R-A2976-AA
3R-A2977-AA
3R-A2978-AA
3R-A3458-AA
3R-A3459-AA
3R-A2979-AA
Linux
1
SN-PBXGF-AB
-
3X-DEPVZ-AA
-
SN-PBXGD-AD
-
SN-PBXGD-AE
26
