QuickSpecs
Options
Step 10 Storage Adapters/Controllers Required if StorageWorks shelf is selected in Step 5 (continued)

Multi-function

PCI (32-bit, 33-MHz) multi-function (single-port 10/100 Ethernet
UTP/RJ45, Ultra2 LVD SCSI, and 2D graphics) adapter. See Step 8.
Module
PCI 2-port UltraSCSI single-ended adapter and 10/100 Mb Ethernet
combo adapter (uses one PCI slot); includes internal 68-pin and 50-pin
HD connectors and two external 68-pin VHDCI SCSI connectors,
requires BN37A-xx cable to connect to single-ended UltraSCSI shelf
VHDCI male-to-VHDCI male UltraSCSI cable,
xx = 02, 2E [2.5], 03, 05, 10, 20 meters
RAID PCI 3-port PCI to Ultra2, 64-bit, LVD backplane RAID controller with
64-MB cache (uses one PCI slot); requires connection to DS-SSL14-Rx
(maximum seven disks supported per channel) or to DS-SL13R-xx
(maximum 14 disks with single channel); requires graphics adapter to
run console utilities (SMOR).
PCI 1-port PCI to Ultra2, 64-bit, LVD backplane RAID controller with
16-MB cache (uses one PCI slot); requires connection to DS-SSL14-Rx
(maximum seven disks supported per channel) or to DS-SL13R-xx
(maximum 14 disks with single channel); requires graphics adapter to
run console utilities (SMOR).
PCI 2-port PCI to Ultra3, 64-bit, 66 MHz, LVD backplane RAID
controller with 128-MB cache (uses one PCI slot); requires connection
to DS-SL13R-xx shelves or BA610-6D card cage.
NOTE: Tru64 UNIX requires V5.1B and TruCluster V5.1B (non-shared
buses only) with Initial Patch Kit:
T64V51BV1AS0001-20021229.tar
Tru64 UNIX requires V5.1A with Initial Patch Kit:
T64V51AV21AS0004-20030206.tar
NOTE: Supports EV68 systems only; no host-based volume shadowing
or shared bus support under OpenVMS
PCI 4-port PCI to Ultra3, 64-bit, 66 MHz, LVD backplane RAID
controller with 256-MB cache (uses one PCI slot); requires connection
to DS-SL13R-xx shelves or BA610-6D card cage.
NOTE: Tru64 UNIX requires V5.1B and TruCluster V5.1B (non-shared
buses only) with Initial Patch Kit:
T64V51BV1AS0001-20021229.tar
Tru64 UNIX requires V5.1A with Initial Patch Kit:
T64V51AV21AS0004-20030206.tar
NOTE: Supports EV68 systems only; no host-based volume shadowing
or shared bus support under OpenVMS
PCI 1-port UltraSCSI RAID controller with 4-MB cache memory (uses
one PCI slot), includes RAID Array 230/Plus Subsystem software and
documentation kit; includes VHDCI female connector; tape drives not
supported; only 9.1-GB disk drives supported, requires BN37A-xx cable
(0.3 to 20 meters) to connect to single-ended UltraSCSI shelf
PCI 3-port UltraSCSI RAID controller with 4-MB cache memory (uses
one PCI slot), includes RAID Array 230/Plus Subsystem Software and
documentation kit; tape drives not supported; only 9.1-GB disk drives
supported; SCSI cable required for each active port; requires BN37X-xx
cable (0.3 to 20 meters) to connect to single-ended UltraSCSI shelf,
and BN31K-0E for external third port connection
Same as KZPAC-CA with 8-MB cache memory
Cache battery backup for KZPAC controller
DA-10392 North America — Version 57 — March 18, 2003
Compaq AlphaServer ES40
Compaq AlphaStation ES40
Maximum # Supported
Tru64 UNIX OpenVMS
1 1
4 4
8 -
8 -
6 per system 6 per system
3 - PCI bus 0 3 - PCI bus 0
4 - PCI bus 1 4 - PCI bus 1
6 per system 6 per system
3 - PCI bus 0 3 - PCI bus 0
4 - PCI bus 1 4 - PCI bus 1
4 4
4 4
4 4
Linux
-
3X-DEPVZ-AA
-
KZPCM-DA
BN37A-xx
-
DS-KZPCC-CE
-
DS-KZPCC-AC
-
3X-KZPDC-BE
-
3X-KZPDC-DF
-
KZPAC-AA
-
KZPAC-CA
-
KZPAC-CB
KZPSC-UB
17
