Samsung ATIV Smart PC Pro XE700T1CA04US User Manual page 59

Hide thumbs

Advertisement

Adjusting the Volume
Using the Sound Recorder
The procedures to record sound using the Windows Recorder are
described below.
1
Connect a microphone to the microphone jack.
Or use built-in microphone.
2
Right-click over the Volume icon
Recording Device.
3
Check if the microphone is set as the default recording
device.
If this is the case, it is already set as the default device. If not,
right-click over the microphone and select Set default.
4
Right-click over the Charms menu > Start
Apps
> Sound Recorder. Then press Start Recording to
record.
on the taskbar and select
to click All
Connecting and using a Ear-set / headset Jack
When there is no sound after connecting an earset or headset,
configure the settings as follows.
1
On the Desktop, click the Charms menu > Settings
Control Panel > Hardware and Sound > Sound > Play tab.
2
Select the Speakers (Intel SST Audio Device (WDM)), click
Set Default and click OK.
Using the Microphone (Optional)
You can optimize the microphone's performance for a single user
only or for sharing with others.
1
On the notification area of the taskbar, right-click the Audio
, and then click Sound Manager.
Manager icon
2
On the Microphone tab, select an option to enable, and then
click OK.
. Narrow: The computer recognizes sound only from a front
45 degree angle. Select this option if only a single user uses
the microphone.
. Wide: The computer recognizes sound from any front angle
so that the microphone can be shared with other people.
However, this option may cause noise.
Chapter 3.
58
Using the computer
>
