To use PPTP as the accessing protocol of the internet, please choose Internet Access from
WAN menu. Then, select PPTP mode for WAN2. The following web page will be shown.
PPTP/L2TP Client
Mode
ISP Access Setup
ISDN Dial Backup
Setup
Vigor2910 Series User's Guide
P a g e f o r P P T P / L 2
P a g e f o r P P T P / L 2
Enable PPTP- Click this radio button to enable a PPTP client to
establish a tunnel to a DSL modem on the WAN interface.
Enable L2TP - Click this radio button to enable a L2TP client to
establish a tunnel to a DSL modem on the WAN interface.
Disable – Click this radio button to close the connection through
PPTP or L2TP.
Server Address - Specify the IP address of the PPTP/L2TP
server if you enable PPTP/L2TP client mode.
Specify Gateway IP Address – Specify the gateway IP address
for DHCP server.
Username -Type in the username provided by ISP in this field.
Password -Type in the password provided by ISP in this field.
Index (1-15) in Schedule Setup - You can type in four sets of time
schedule for your request. All the schedules can be set previously
in Application – Schedule web page and you can use the number
that you have set in that web page.
This setting is available for the routers supporting ISDN function
only. Before utilizing the ISDN dial backup feature, you must
create a dial backup profile first. Please click Internet Access
Setup > Dialing to a Single ISP to enter the backup profile.
Due to the absence of the ISDN interface in some models, the
ISDN dial backup feature and its associated setup options are not
available to them. Please refer to the previous part for further
