Name (on Backup Profile
field)
Member1 (on Backup
Profile field)
Active (on Backup Profile
field)
Type (on Backup Profile
field)
Member2 (on Backup
Profile field)
Status
Profile Name
Member 1/Member2
Add
Edit
Delete
Display the name of VPN TRUNK profile.
Display the dial-out profile selected from the Member1 drop
down list below.
"Yes" means normal condition.
"No" means the state might be disabled or that profile
currently is set with Dial-in mode (for call direction) in LAN
to LAN.
Display the connection type for that profile, such as IPSec,
PPTP, L2TP, L2TP over IPSec (NICE), L2TP over
IPSec(MUST) and so on.
Display the dial-out profile selected from the Member2 drop
down list below.
After choosing one of the profile listed above, please click
Enable to activate this profile. If you click Disable, the
selected VPN Backup profile will not have any effect for VPN
tunnel.
Type a name for VPN Backup profile. Each profile can group
two VPN connections set in LAN to LAN. The saved VPN
profiles in LAN to LAN will be shown on Member1 and
Member2 fields.
Display the selection for LAN to LAN dial-out profiles
(configured in VPN and Remote Access >> LAN to LAN)
for you to choose for grouping under certain VPN backup
profile.
No - Index number of LAN to LAN dial-out profile.
Name - Profile name of AN-to-LAN dial-out profile.
Connection Type - Connection type of AN-to-LAN dial-out
profile.
VPN ServerIP (Private Network) - VPN Server IP of LAN to
LAN dial-out profiles.
Add and save new profile to the backup profile list. The
corresponding members (LAN to LAN profiles) grouped in
such new VPN TRUNK profile will be locked. The profiles in
LAN to LAN will be displayed in red.
Click this button to save the changes to the Status (Enable or
Disable), profile name, member1 or member2.
Click this button to delete the selected VPN TRUNK profile.
The corresponding members (LAN to LAN profiles) grouped
in the deleted VPN TRUNK profile will be released and that
profiles in LAN to LAN will be displayed in black.
