Confirm Password
Home Folder
Access Rule
Before you click OK, you have to insert a USB diskette into the USB interface of the Vigor
router. Otherwise, you cannot save the configuration.
3 . 1 5 . 3 U S B D i s k
3 . 1 5 . 3 U S B D i s k
This page is to monitor the status for the FTP users who accessing into FTP server (USB
diskette) via the Vigor router.
Connection Status
Disk Capacity
Free Capacity
Username
password specified here for accessing into USB storage
diskette.
Type the password again to make confirmation.
It determines the range for the client to access into.
The user can enter a directory name in this field. Then,
after clicking OK, the router will create the specific/new
folder in the USB diskette. In addition, if the user types
"/" here, he/she can access into all of the disk folders and
files in USB diskette.
Note: When write protect status for the USB diskette is
ON, you cannot type any new folder name in this field.
Only "/" can be used in such case.
It determines the authority for such profile. Any user, who
uses such profile for accessing into USB diskette, must follow
the rule specified here.
File – Check the items (Read, Write and Delete) for such
profile.
Directory –Check the items (List, Create and Remove) for
such profile.
S t a t u s
S t a t u s
If there is no USB diskette connected to Vigor router, "No
Disk Connected" will be shown here.
It displays the total capacity of the USB diskette.
It displays the free space of the USB diskette. Click Refresh
at any time to get new status for free capacity.
It displays the username that user uses to login to the FTP
server.
