3.
Set Inbound/Outbound bandwidth.
4.
Return to previous page. Enter the Name of Index Class 1 by clicking Edit link. Type
the name "E-mail" for Class 1.
5.
For this index, the user will set reserved bandwidth (e.g., 25%) for E-mail using
protocol POP3 and SMTP.
Vigor2910 Series User's Guide
Note: The rate of outbound/inbound must be smaller than the real
bandwidth to ensure correct calculation of QoS. It is suggested to set the
bandwidth value for inbound/outbound as 80% - 85% of physical network
speed provided by ISP to maximize the QoS performance.
229
