Safety Is Your Responsibility (continued from page 5)
• Keep exposed skin away from escaping gas when installing
or removing air supply cylinder or if the marker or air supply is
E
leaking. Compressed air, CO
very cold and can cause frostbite under certain conditions.
N
• Use only .68 caliber paintballs, never load or fire any foreign objects.
G
• Avoid alcoholic beverages before and during the use of this
L
marker. Handling markers while under the influence of drugs
or alcohol is a criminal disregard for public safety.
S
• Avoid shooting an opponent at point blank, 6 feet or less.
H
• Familiarize yourself with instructions listed on air supply
cylinder or adaptor. Contact the air supply cylinder or adaptor
manufacturer with any questions.
• Always measure your marker's velocity before playing
paintball and never shoot at velocities in excess of 300 feet
per second (see instructions on page 7).

GETTING STARTED

Eye protection designed for paintball use must be worn by the user
and any person within range.
STEP 1) Prepare Marker for Air Supply Cylinder Installation
• For Models: 98 Custom
E-Trigger TM - You must first read and follow E-Trigger Operating
Instructions (on pages 8-13) before performing STEP 2.
• For 98 Custom TM , 98 Custom Response
Custom Pro TM Response
STEP 2) Air Supply Cylinder Installation
• Do not pressurize a partially assembled paintball marker.
• First install barrel sleeve (see instructions on page 2).
• Next put trigger safety in Safe Mode (see instructions on page 4).
• Next you need to cock the marker by sliding the bolt handle all
the way back until it locks into place. Always keep marker in the
cocked position when air supply is attached to marker. This will
help prevent an accidental discharge.
• To install the air supply cylinder, lubricate the cylinder valve o-ring with a
little gun oil then insert the cylinder valve end into the air supply adapter
at the back end of the marker grip. Twist the cylinder clockwise
the marker until it stops. Adjust the butt plate if necessary. Your marker
is ready to fire once you switch to Fire Mode from Safe Mode. If the tank
is full and you do not hear the air supply engage, the pin valve could be
too short or the pin valve seal is damaged.
, and nitrogen gasses are
2
TM With E-Trigger TM or Custom Pro
TM , Custom Pro
TM go to STEP 2.
Getting Started (continued on page 7)
6
Getting Started (continued from page 6)
STEP 3) Hopper Installation
• Barrel Sleeve must be installed (see page 2) and safety in
Safe Mode (see page 4) before filling the hopper.
• Make sure that the feed elbow and hopper are clean and
free of any sharp edges to keep paintballs feeding into the
marker smoothly.
• Install the hopper neck into the feed elbow of your marker
and tighten the hopper down with a 3/16" allen wrench.
NOTE: Do not overtighten or the elbow may break. With the barrel
sleeve installed and safety in Safe Mode, you are now ready to
load your hopper with paintballs. Fill hopper and only remove
barrel sleeve and turn off the safety when ready to shoot.
STEP 4) Rate of Fire Adjustments and Troubleshooting
• For RESPONSE
Rate of Fire instructions (on page 13) before performing STEP 5.
• For E-TRIGGER
Instructions (on pages 8-13); before performing STEP 5.
• For 98 Custom
STEP 5) Velocity Adjustment
Each time you play paintball,
TM With
the velocity of your paintball
marker should be checked
with a chronograph, an
TM and
instrument for measuring
velocity, prior to playing
paintball to verify that the
marker's velocity is set below
300 feet per second or less if
required by playing field.
To adjust the velocity use the 5/32" allen wrench included with
your marker. The velocity adjustment screw is located on left side
receiver. To adjust the velocity down, turn the screw inward or
clockwise
counterclockwise
NOTE: You must turn the velocity screw all the way in
into
doing any disassembly.
STEP 6) Rear Sight Adjustment
If your paintball is hitting low, slide the rear sight back towards rear
of marker. Do the opposite if paintball is hitting high.
TM markers - complete Tuning The Response Trigger
TM markers - read and follow E-Trigger Operating
TM and Custom Pro TM markers - Go to STEP 5.
. To turn the velocity up, turn the screw out or
. Do not remove velocity screw.
7
E
N
G
L
I
S
H
Velocity
Adjustment
Screw
5/32" Allen Wrench
before
