Hardware Installation

General instructions for installing the ExpressCard are
provided. Since the design of systems may vary, refer to
your system's reference manual for further information,
if needed.
1. Connect the ExpressCard 1P Cable to the cable
connector on the ExpressCard.
2. Insert the CyberParallel ExpressCard into the
ExpressCard slot of your system with the label
facing up. Make sure it is inserted all the way in for
a solid connection.
Note: When connecting/disconnecting devices, hold
the CyberParallel ExpressCard so it does not move
from side to side, otherwise it may eject from the
slot or lose connection.
Figure 3: Connecting the cable
3
