Chapter 2
Installation
This chapter will guide you through the installation of your
CyberParallel PCI. There are no jumpers or switches to set for
this PCI Plug-n-Play board.
2-1 Installing the CyberParallel PCI
Proceed with the following instructions to install the board in
your computer. General installation instructions are given
since the design of computer cases varies. Refer to your
computer's reference manual whenever in doubt.
Note: Leave the CyberParallel PCI board in its
static-resistant bag until you are ready to install it.
1. Turn OFF the power to your computer and any other
connected peripheral devices. Follow the precautions for
static electricity discharge.
CAUTION: STATIC ELECTRICITY DISCHARGE
may permanently damage your system. In order to
avoid possible static electricity discharge during
installation procedures, please follow the guidelines
below:
• Discharge any static electricity build up in your body by
touching a large grounded metal surface such as the
computer case (if plugged in), a metal window frame,
refrigerator, or water tap for a few seconds.
• During installation procedures, avoid any contact with
internal parts. Handle cards only by their edges.
CAUTION: Disconnect the AC power source
before removing the cover.
Installation
2-1

Advertisement

loading

Summary of Contents for SIIG CyberParallel PCI

  • Page 1: Chapter 2 Installation

    Chapter 2 Installation This chapter will guide you through the installation of your CyberParallel PCI. There are no jumpers or switches to set for this PCI Plug-n-Play board. 2-1 Installing the CyberParallel PCI Proceed with the following instructions to install the board in your computer.
  • Page 2 CyberParallel PCI after it’s installed. Fig. 2-1. Remove the Slot Bracket 6. To install the CyberParallel PCI, carefully align the board’s bus connector with the selected expansion slot on the motherboard. Push the board down firmly, but gently,...
  • Page 3 NOTE: Hold the board by its external edges only. Try to avoid touching the components, connectors or pins. Fig. 2-2. Install the CyberParallel PCI Board 7. Replace the slot bracket's holding screw to secure the board to the rear slot panel.
  • Page 4: Installing The Drivers And Utilities

    1. From the main desktop, click on My Computer, then double- click on Control Panel, System, and Device Manager. 2. Double-click on either Ports (COM & LPT) or SIIG Cyber PCI device options. SIIG CyberParallel PCI Board should be displayed when successfully installed. The port is ready...
  • Page 5 From the desktop, double-click on My Computer, then 3 1/2 Floppy (A:) and NT subdirectory. 4. Double-click on the setup icon. When the program opens to the “SIIG Cyber PCI Welcome” window, click on Next to continue. From the “Choose Destination Location” window, click Next to install the driver files in the default folder.
  • Page 6 The I/O port address and mode setting for the parallel port are automatically assigned during the system's startup. If you like to view the current system setting for the CyberParallel PCI, proceed with the following instruction to run the CB10xpc.exe: •...
  • Page 7 Installation CB10xsu.exe Mode Change Your CyberParallel PCI supports EPP/ECP, ECP, EPP, and BPP/SPP modes. The default mode setting is EPP/ECP. You can change the mode by running cb10xsu.exe. 1. Go to My Computer in Windows 95 and click on the subdirectory where the DOS utility files are stored.
  • Page 8 CyberParallel PCI User's Manual...
