SIIG CyberParallel Dual Quick Installation Manual

Hide thumbs Also See for CyberParallel Dual:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
Introducing the CyberParallel Dual
The CyberParallel Dual is a high-speed parallel I/O card
for parallel device connections. It provides 2 ECP/EPP
parallel ports which support data transfer rates up to
1.5 MB/sec.
Features and Benefits
•
Conforms to PCI v2.2 Plug and Play
•
Can be installed in 32-/64-bit, 3.3v/5v PCI and
PCI-X slots
•
Full support for DOS and Windows based software
•
PCI IRQ sharing feature reduces IRQ conflicts
•
Compliant with IEEE 1284-1994 parallel port
standard
•
Works with various types of parallel port devices
including printers, removable drives, scanners,
CD-R/RWs, and more
•
Supports ECP/EPP, Bi-directional Parallel Port
(PS2) and Standard Parallel Port (SPP) modes
System Requirements
•
Pentium
PCI slot
•
Windows
/64-bit)/Server 2003 (32-/64-bit)/Vista (32-/64-bit)
04-0328C
CyberParallel Dual

Quick Installation Guide

or equivalent computer with an available
®
95/98/98SE/ME/NT 4.0/2000/XP (32-
®
1

Advertisement

Table of Contents
loading

Related Manuals for SIIG CyberParallel Dual

Summary of Contents for SIIG CyberParallel Dual

  • Page 1: Quick Installation Guide

    CyberParallel Dual Quick Installation Guide Introducing the CyberParallel Dual The CyberParallel Dual is a high-speed parallel I/O card for parallel device connections. It provides 2 ECP/EPP parallel ports which support data transfer rates up to 1.5 MB/sec. Features and Benefits •...

  • Page 2: Package Contents

    Package Contents • CyberParallel Dual board • Driver CD • DB25 parallel port cable (for 2nd parallel port) • Quick installation guide Board Layout Parallel Port 2 (P2)* Parallel Port 1 (P1) Figure 1. Cyber Parallel Dual layout *Note: When connecting the DB25 parallel port...

  • Page 3: Hardware Installation

    Hardware Installation General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed. Static Electricity Discharge may permanently damage your system. Discharge any static electricity build up in your body by touching your computer case for a few seconds.

  • Page 4: Software Installation

    Software Installation This section provides the steps on how to install the CyberParallel Dual drivers. Please make sure the board is installed before proceeding with the driver installation. Windows 95 At the Update Device Driver Wizard, click Next. Insert the driver CD and click Other Locations.
  • Page 5 Windows ME At the Add New Hardware Wizard, choose Specify the location of the driver (Advanced), then click Next. Check Specify a location, uncheck the other box, insert the driver CD, type in X:\2P\ME, then click Next. (Change X: to match your CD-ROM drive letter) Click Next, then Finish.
  • Page 6 Windows XP At the Found New Hardware Wizard, For XP SP2 or later: Select No, not this time, click Next. Select Install from a list or specific location (Advanced), then click Next. For XP SP1 or earlier: Select Install from a list or specific location (Advanced), then click Next.
  • Page 7 Windows Server 2003 At the Found New Hardware Wizard, For Server 2003 SP1 or later: Select No, not this time, click Next. Select Install from a list or specific location (Advanced), then click Next. For Server 2003: Select Install from a list or specific location (Advanced), then click Next.
  • Page 8 Windows Vista ™ At the Found New Hardware window, click Locate and install driver software (recommended), click Continue. When prompted, insert the driver CD and the driver will install automatically. At The software for this device has been successfully installed window, click Close to complete the installation.
  • Page 9 Windows NT 4.0 Click Start, Settings, Control Panel. Double click NetMos Multi-I/O Ports icon, click Parallel Port tab, two parallel ports should be listed under Ports. Windows 2000/XP (32-bit)/Server 2003 (32-bit) Right click My Computer, click Manage, then click Device Manger. Double click Multifunction adapters, NetMos...
  • Page 10 Blank Page...

  • Page 11: Technical Support And Warranty

    Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. SIIG RMA department can also be reached at (510) 413-5333.
  • Page 12 6078 Stewart Avenue Fremont, CA 94538-3152, USA CyberParallel Dual is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Pentium is a registered trademark of Intel Corporation.
