SIIG CyberParallel Dual Installation Manual

Chapter 2
Installation
This chapter will guide you through the installation of your
CyberParallel Dual. There are no jumpers or switches to set for
this PCI Plug-n-Play board.

2-1 Hardware Installation

General instructions for installing the board are given since the
design of computer chassis varies. Refer to your computer's
reference manual for information on removing the computer
cover.
1. Turn OFF the power to your computer and any other
connected peripheral devices.
2. Unplug the power cord from the back of the computer.
3. Remove the computer's cover by removing its mounting
screws and sliding off the cover.
4. Select an available 32-bit PCI slot for the board with an
adjacent slot for installing the connector bracket.
5. Remove the slot bracket by unscrewing the holding screw
and sliding it out. Save this screw for securing the board
after it's installed. Follow the same procedures for the
connector bracket.
6. To install the CyberParallel Dual, carefully align the board's
bus connector to the expansion slot on the motherboard.
Push the board down firmly, but gently, until it is well
seated.
7. To install the connector bracket, carefully slide it into the
selected slot where the slot bracket had been removed.
Installation
2-1
