Hardware Installation

General instructions for installing the card are provided
below. Since the design of computer cases and
motherboards vary, refer to your computer's reference
manual for further information, if needed.
Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges.
1. Turn OFF the power to your computer.
2. Unplug the power cord and remove your computer's
cover.
3. Remove the slot bracket from an available PCI slot.
4. If you need the second parallel port, connect the
25-pin ribbon cable connector now and remove
another slot bracket cover from an available PCI
slot. See Figure 1 on page 2 for more details. Skip
this step if you need only one parallel port.
5. Carefully align the card to the selected PCI slot,
push the board down firmly, but gently, until it is
well seated.
6. Replace the slot bracket holding screw to secure the
card.
7. Mount the second parallel port and secure it with
the slot bracket holding screw. Skip this step if you
need only one parallel port.
8. Replace the computer cover and reconnect the power
cord.
