Package Contents

• CyberParallel Dual board
• Driver CD
• DB25 parallel port cable (for 2nd parallel port)
• Quick installation guide

Board Layout

Parallel Port 1
(P1)
*Note: When connecting the DB25 parallel port
cable to Parallel Port 2 (P2), position the ribbon
cable so the colored stripe is on the side closest to
the slot bracket.
2
Parallel Port 2
(P2)*
Figure 1. Cyber Parallel Dual layout
