Introducing the CyberParallel Dual
The CyberParallel Dual is a high-speed parallel I/O card
for parallel device connections. It provides 2 ECP/EPP
parallel ports which support data transfer rates up to
1.5 MB/sec.
Features and Benefits
•
Conforms to PCI v2.2 Plug and Play
•
Can be installed in 32-/64-bit, 3.3v/5v PCI and
PCI-X slots
•
Full support for DOS and Windows based software
•
PCI IRQ sharing feature reduces IRQ conflicts
•
Compliant with IEEE 1284-1994 parallel port
standard
•
Works with various types of parallel port devices
including printers, removable drives, scanners,
CD-R/RWs, and more
•
Supports ECP/EPP, Bi-directional Parallel Port
(PS2) and Standard Parallel Port (SPP) modes
System Requirements
•
Pentium or equivalent computer with an available
PCI slot
•
DOS, Windows 95/98/98 SE/ME/NT 4.0/2000/
XP/Server 2003
04-0328B
CyberParallel Dual
Quick Installation Guide
1
Advertisement
Table of Contents
Related Manuals for SIIG CyberParallel Dual
Summary of Contents for SIIG CyberParallel Dual
- Page 1 CyberParallel Dual Quick Installation Guide Introducing the CyberParallel Dual The CyberParallel Dual is a high-speed parallel I/O card for parallel device connections. It provides 2 ECP/EPP parallel ports which support data transfer rates up to 1.5 MB/sec. Features and Benefits •...
-
Page 2: Package Contents
Package Contents • (1) CyberParallel Dual board • (1) Driver CD • (1) DB25 parallel port cable (for 2nd parallel port) • This quick installation guide Board Layout Parallel Port 2 (P2)* Parallel Port 1 (P1) Figure 1. Cyber Parallel Dual layout... -
Page 3: Hardware Installation
Hardware Installation General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed. Caution: Static Electricity Discharge may permanently damage your system. To avoid possible static electricity discharge during the installation, please follow the guidelines below: •... -
Page 4: Software Installation
Figure 2. Inserting the PCI Board Software Installation This section provides the steps on how to install the CyberParallel Dual drivers. Please make sure the board is installed before proceeding with the driver installation. Windows 95 Driver Installation At the Update Device Driver Wizard, click Next. - Page 5 Windows 98/98SE Driver Installation At the Add New Hardware Wizard, click Next. Select Search for the best driver for your device (Recommended), then click Next. Select Specify a location, uncheck the other boxes, insert the driver CD, type in X:\2P\98, then click Next.
- Page 6 Windows 2000 Driver Installation At the Found New Hardware Wizard, click Next. Select Search for a suitable driver for my device (Recommended), then click Next. Select Specify the location, uncheck the other boxes, then click Next. Insert the driver CD, type in X:\2P\2000, then click OK.
- Page 7 Insert the driver CD, check Include this location in the search, uncheck the other box, type in X:\2P\2003, then click Next. (Change X: to match your CD-ROM drive letter) At the Hardware Installation window, click Continue Anyway, then click Finish. Our driver has been thoroughly tested for stability and compatibility.
-
Page 8: Troubleshooting
For Windows NT 4.0: Click Start, Settings, Control Panel. Double click NetMos Multi-I/O Ports icon, click Parallel Port tab, two parallel ports should be listed under Ports. For Windows 2000/XP/Server 2003: Right click My Computer, click Manage, then click Device Manger. Double click Multifunction adapters, NetMos 9835 PCI... -
Page 9: Technical Support And Warranty
SIIG will refuse to accept any shipping package, and will not be responsible for a product returned without an RMA number posted on the outside of the shipping carton. You are responsible for the cost of shipping the product to SIIG • at the following address: SIIG, Inc. - Page 10 Fremont, CA 94538-3152 CyberParallel Dual is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. Other names used in publication are for identification only and may be trademarks of their respective companies.
