LED Operation
Uplink Port
LNK/ACT*
*Located on RJ-45 of downlink port 3.
Downlink Ports
Glows amber when link is established on port.
Blinks amber during data activity on port.
Uplink and Downlink Ports
LNK/ACT
Glows green when link is established on port.
Blinks green during data activity on port.
FDX/COL
Glows amber when port is operating in Full-Duplex.
Blinks amber when collisions occur on port.
AccessEtherLinX/3
Glows green when link is established on port.
Blinks green during data activity on port.
AccessEtherLinX/4
