Powering the MiniMc

The MiniMc includes multiple powering options:
•
A country-specific, high-reliability AC power adapter (included)
•
IE-PowerTray/18 for Rack Mounting

LED Operation

Each MiniMc includes two LEDs, located on the RJ-45 connector. LED functions are
as follows:
FX TX
FX LNK/ACT Glows green when a link is established on the fiber port; blinks green
when activity is detected on the fiber port.
TX LNK/ACT Glows green when a link is established on the copper port; blinks green
when activity is detected on the copper port.

Specifications

AC Wall Adapter
100 to 240 ±10% VAC input, 5 VDC output, 2A max.
Operating Temperature
+14°F to +122°F (-10C° to +50°C)
Storage Temperature
-31°C to +167° F (-35C° to +75°C)
Humidity:
5% to 95% (non-condensing), 0 – 10,000 ft. altitude
Input Power Consumption (Typical, varies with optical transceiver type)
500mA@5 VDC
FX TX
2
