Wall-Mount Installation
To wall mount the AccessEtherLinX/3, use the supplied screws to attach the wall-
mount bracket to the AccessEtherLinX/3, then mount the unit to the wall. Attach the
cables between the AccessEtherLinX/3 and each device that will be interconnected
and then plug the unit into a reliable, filtered power source.
Rack-Mount Installation
The Rack-Mount kits for the AccessEtherLinX/4 are sold separately:
Description
19" Rack-Mount 895-39226
brackets
19" Rack-Mount 895-39949
shelf
Single-strand fiber products use optics that transmit and receive on two different wavelength.
Single-strand fiber products must be deployed in pairs, connecting two compatible single-
strand fiber products. Connect the 852-10133 (1310 xmt and 1550 rcv), for example, to a
product with 1550 xmt and 1310 rcv, e.g. 852-10134 (1550 xmt and 1310 rcv.) The two
connected products must also have the same speed and distance capabilities (i.e. both are
single-mode [20km] or both are single/PLUS [40km]).

Features

AutoCross Feature for Twisted Pair Connection
All twisted pair ports on the AccessEtherLinX include AutoCross, a feature which
automatically selects between a crossover workstation or pass-through connection
depending on the connected device.
Software Configurable Features
The FiberAlert, as well as Auto-Negotiation (Selective Advertising) and Bandwidth
Control features are all configurable via the management software or via serial
configuration or Telnet session.
Refer to the AccessEtherLinX help file for additional information.
Part Accessories
Number
Includes two brackets
that screw onto either
side of the
AccessEtherLinX /4.
Fits into the 19" rack
and holds up to 3 units
of the AccessEtherLinX/4.
INSTALLATION TIP
2
Installation
The brackets are
attached to the unit and
then the AccessEtherLinX
/4 is installed into the
rack.
The AccessEtherLinX /4
can be secured to the
shelf.
