Command List
I = Enter New Saved Parameter Values
P = Change Password
T = New Trap Destination
K = Remove ALL Trap Destinations
C = New Community String
U = Delete ALL Community Strings
D = Enable/Disable DHCP
E = End Session
Space Bar = Opens device specific configuration options (tasks, memory,
cleandb, download, version, reboot, sysname, accounts, and
modules).
Reboot after making any modifications to the Saved Values or the changes will not take
effect. To reboot, type Reboot at the prompt on the main configuration screen, or turn the
chassis power OFF then ON again.
Because a Delete key is not available on VT-100 terminal emulators, use the F2 key instead.
Assigning TCP/IP Information
To modify the Saved Parameter Values (i.e., assign IP address and subnet mask), press
I. Enter the IP address and subnet mask for the connected device, pressing Enter
after each value. A default gateway can also be assigned (press Enter to skip). When
finished, press Enter and then type Reboot for the changes to take effect. The Saved
Values and Current Values should now both display the changes made (e.g., new IP
address and subnet mask).
Change Serial Password
By default, no password is assigned via the serial port. However, one can be assigned
by pressing P from the main configuration screen. Enter a password; passwords are
case sensitive and should be no more than eight characters in length, with no spaces;
press Enter. This will be requested whenever logging on or off. To remove password
protection, select P and instead of entering a password press Enter.
Passwords are a way to make the management of network devices secure. It is the
responsibility of the network administrator to store and maintain the password lists.
Assigning Trap Destinations
Traps are sent by the manageable device to a management PC when a certain event
takes place. To enter a trap destination, press T. When asked to "Enter a New IP
Address.", type the IP address of the destination device and press Enter. Then, type
NOTE
7
