2. Click Patches and utilities.
3. Select the Data Protector version with which you will be using the integration.
4. Select Cross operating system (BIOS, Firmware, Diagnostics, etc.)
5. In the Software-Solutions section, click Data Protector Release x.xx / Xen
Server integration packet and download the package from the subsequent
page.
When you have obtained the scripts, install them as follows:
1. If you have downloaded the package, unzip
xenServer_backup_solution.zip.
2. Copy all of the scripts to your preferred location on the Data Protector Disk Agent
host. For security reasons, the following locations are recommended:
• On Windows: Data_Protector_home\bin
• On Linux: /opt/omni/bin
Make a note of this location: You will need it later.
3. If you do not already have the xenAPI.py file:
a. Go to http://community.citrix.com/display/xs/Download+SDKs.
b. Go to the download section for the version of XenServer that you are using.
c. Download the XenAPI.py.
4. Copy XenAPI.py to the same location as the integration scripts.
5. Create a folder with read and write permissions, for temporary use during
backup. Create the folder as follows:
• On Windows: C:\tmp\backup\
• On Linux: /tmp/backup/
IMPORTANT:
It is the contents of this directory that will actually be backed up to the backup device
by Data Protector. It must therefore have enough space available to cope with your
largest likely backup. For instance, if you want to be able to backup all the virtual
machines on your XenServer in one operation, there must be enough space for all
of them. The folder will be referred to as the temporary backup folder in these
instructions.
Integration guide for VMware Virtual Infrastructure, Sybase, Network Node Manager,
and Network Data Management Protocol Server 203
