Figure 72 Example layout

Installation of the integration

This section gives detailed instructions for the installation of the XenServer integration.

Prerequisites

The machine on which the integration is to be installed must be a Data Protector
client (shown as DP Client in
and must be a member of a Data Protector Cell. For further details, refer to the HP
Data Protector installation and licensing guide.
The Data Protector Disk Agent must be installed first, since other software must be
installed in specific Data Protector directories.
The following software must then be installed on the Disk Agent host:
• Python version 2.5.x or 2.6.x (available from http://www.python.org/download).
This must be installed first. (Also, see the note regarding Pycurl below).
Install the software in the following directories:
• On Windows: Data_Protector_home\bin
• On Linux: /opt/omni/bin
• Curl with libcurl version 7.18.x or 7.19.x (available from
download.html).
Note that the package installed must contain libcurl.
• Pycurl (available from http://pycurl.sourceforge.net/).
If you prefer there are some compiled versions available from:
• For Windows:
• For Linux:
Integration guide for VMware Virtual Infrastructure, Sybase, Network Node Manager,
Figure 72) with the Data Protector Disk Agent installed
http://pycurl.sourceforge.net/download/
http://rpm.pbone.net/index.php3
and Network Data Management Protocol Server
http://curl.haxx.se/
201
