Multiple Line Keys Per Registration - Polycom SIP 3.0.2 Administrator's Manual

Administrator's Guide SoundPoint IP / SoundStation IP
Configuration File:
Central
sip.cfg
(boot server)

Multiple Line Keys per Registration

Configuration file:
Central
phone1.cfg
(boot server)
Web Server
Local
(if enabled)
Local Phone User
Interface
4 - 24
• The phone keys without removable key caps cannot be remapped. These
include:
— Any keys on the dial pad
— Volume control
— Handsfree, Mute, Headset
— Hold
— Navigation Cluster
Configuration changes can performed centrally at the boot server:
Set the key scrolling timeout, key functions, and sub-pointers for each
key (usually not necessary).
For more information, refer to
•
For more information on the default feature key layouts, refer to
Feature Key Layouts on page C-10.
More than one Line Key can be allocated to a single registration (phone
number or line) on SoundPoint IP phones. The number of Line Keys allocated
per registration is configurable.
Configuration changes can performed centrally at the boot server or locally:
Specify the number of line keys to assign per registration.
For more information, refer to
•
Specify the number of line keys to assign per registration.
Navigate to http://<phoneIPAddress>/reg.htm
Changes are saved to local flash and backed up to <Ethernet
address>-phone.cfg on the boot server. Changes will permanently
override global settings unless deleted through the Reset Local
Config menu selection and the <Ethernet address>-phone.cfg is
removed from the boot server.
Specify the number of line keys to assign per registration using the
SIP Configuration menu. Either the Web Server or the boot server
configuration files or the local phone user interface should be used to
configure registrations, not a mixture of these options. When the SIP
Configuration menu is used, it is assumed that all registrations use
the same server.
Keys <key/> on page A-69.
Default
Registration <reg/> on page A-89.
