IEEE 802.1p/Q

Configuration file:
Central
sip.cfg
(boot server)
Web Server
Local
(if enabled)
Local Phone User
Interface

Voice Quality Monitoring

Note
4 - 52
The phone will tag all Ethernet packets it transmits with an 802.1Q VLAN
header for one of the following reasons:
• When it has a valid VLAN ID set in its network configuration
• When it is instructed to tag packets through Cisco Discovery Protocol
(CDP) running on a connected Ethernet switch
• When a VLAN ID is obtained from DHCP (refer to
3-7)
The 802.1p/Q user_priority field can be set to a value from 0 to 7. The
user_priority can be configured specifically for RTP packets and call control
packets, such as SIP signaling packets, with default settings configurable for
all other packets.
Configuration changes can performed centrally at the boot server or locally:
Specify default and protocol-specific 802.1p/Q settings.
For more information, refer to
•
<ethernet/>
Specify 802.1p/Q settings.
Navigate to http://<phoneIPAddress>/netConf.htm#qo
Specify whether CDP is to be used or manually set the VLAN ID or
configure DHCP VLAN Discovery.
Phase 1: bootRom - Navigate to: SETUP menu during auto-boot
countdown.
Phase 2: Application - Navigate to:
Menu>Settings>Advanced>Admin Settings>Network
Configuration
For more information, refer to
•
3-2.
This feature requires a license key for activation. Using this feature may require
purchase of a license key or activation by Polycom channels. For more information,
contact your Certified Polycom Reseller.
The SoundPoint IP phones can be configured to generate various quality
metrics for listening and conversational quality. These metrics can be sent
between the phones in RTCP XR packets. The metrics can also be downloaded
in SIP messages to a central voice quality report collector. The collection of
these metrics is supported on the SoundPoint IP 330/320, 430, 501, 550, 560,
600, 601, and 650 and the SoundStation IP 4000.
Ethernet IEEE 802.1p/Q
on page A-50.
Setting Up the Network
DHCP Menu on page
on page
