Polycom SIP 3.0.2 Administrator's Manual page 224

Administrator's Guide SoundPoint IP / SoundStation IP
Caution
Name
device.set
device.xxx.yyy.set
device.net.ipAddress
device.net.subnetMask
device.net.IPgateway
device.net.vlanId
device.net.cdpEnabled
device.dhcp.enabled
A - 106
This feature is very powerful and should be used with caution. For example, an
incorrect setting could set the IP Address of multiple phones to the same value.
Note that some parameters may be ignored, for example if DHCP is enabled it will
still override the value set with device.net.ipAddress.
Individual parameters are checked to see whether they are in range, however, the
interaction between parameters is not checked. If a parameter is out of range, an
error message will appear in the log file and parameter will not be used.
Incorrect configuration could cause phones to get into a reboot loop. For example,
server A has a configuration file that specifies that server B should be used, which
has a configuration file that specifies that server A should be used.
Polycom recommends that you test the new configuration files on two phones
before initializing all phones. This should detect any errors including IP address
conflicts.
This flash attributes are defined as follows:
Possible Values
0 or 1
default = 0
0 or 1
default = 0
dotted-decimal IP address
dotted-decimal IP address
dotted-decimal IP address
Null, 0 to 4094
0 or 1
0 or 1
Description
If set to 0, do not use any device.xxx.yyy fields to
set any parameters. Set this to 0 after the initial
installation.
If set to 1, use the device.xxx.yyy fields that have
device.xxx.yyy.set = 1. Set this to 1 for the initial
installation only.
If set to 0, do not use the device.xxx.yyy value.
If set to 1, use the device.xxx.yyy value.
For example, if device.net.ipAddress.set = 1,
then use the contents of the device.net.ipAddress
field.
Phone's IP address.
Note: This field is not used when DHCP client is
enabled.
Phone's subnet mask.
Note: This field is not used when DHCP client is
enabled.
Phone's default router / IP gateway.
Note: This field is not used when DHCP client is
enabled.
Phone's 802.1Q VLAN identifier.
Note: Null = no VLAN tagging
If set to 1, the phone will attempt to determine its
VLAN ID through the CDP.
For description, refer to DHCP or Manual TCP/IP
Setup on page 3-2.
