ID selection
Up to four CM403 modules can be installed in a System 5 console. Set the ID switches
on the back panel of the module according to Table 1:
CM403 #
1
2
3
4
NOTE: In a dual-operator console, all CM403 modules are connected to the master
console, which is used for monitoring and record control.

External Record Control

The Euphonix EXT 25-pin connector on the rear panel of the CM403 accepts two
external closures:
Function
Record Out
The +5V output on the connector is internally protected by a 200 mA self-resetting fuse.
The active-high switch inputs are TTL-level inputs with 100 K pull-down resistors.
Table 1 CM403 ID Switch Settings
Frame ID
1H
1H
1H
1H
Table 2
Switch Input
Record In Pin 25
Pin 11
Module ID
13
14
15
16
+5 V
Pin 13
Pin 13
6
Position # in
eMix
1–29
1–30
1–31
1–32
