Power Management
Supports Wake on LAN
Supports Wake on USB
Supports Resume From Modem Ring
Audio
High Definition Audio Compliant Interface
3D Stereo Enhanced Sound System
S/PDIF Digital Output
Built-In Microphone
5 * Built-In Speakers (Supporting 2 Channel Stereo)
Interface
Two USB 2.0 Ports
Two USB 3.0 Ports
One eSATA Port
One IEEE1394a Port
One DVI-I Out Port
One HDMI Out Port
One Headphone-Out Jack
One Microphone-In Jack
One S/PDIF-Out Jack
One Line-In Jack
One RJ-11 Jack
One RJ-45 LAN Jack
One DC-In Jack
Note: External 5.1CH Audio Output Supported by
Headphone, Microphone and Line-In Jacks
Power
Full Range AC/DC Adapter
AC input 100 - 240V, 50 - 60Hz,
DC Output 19V, 9.47A (180W)
Removable Polymer Smart Lithium-Ion Battery Pack,
42.18WH
Dimensions & Weight
412mm (w) * 279mm (d) * 39-56.8mm (h)
4kg With ODD & Battery
Communication
Built-In 56K Fax Modem V.90 & V.92 Compliant (Factory
Option)
Built-In 10/100/1000Mb Base-TX Ethernet LAN
Intel® WiFi Link Wireless LAN Module 5300 3*3 802.11 a/g/n
Half Mini-Card with PCIe Interface (Factory Option)
3rd Party 802.11b/g/n Half Mini-Card Wireless LAN Module
with PCIe Interface (Factory Option)
Bluetooth 2.1 + EDR (Enhanced Data Rate) Module with
USB Interface (Factory Option)
2.0M Pixel USB PC Camera Module with USB Interface
(Factory Option)
Operating System
Windows® Vista (with Service Pack 2)
Windows® 7
Introduction
Overview 1 - 3
