EUROCOM Notebook User Manual page 102

Upgrading The Computer
6
Figure 6 - 4
HDD & Case
Assembly
Removal
(Model B
Computers Only)
6 - 6 Upgrading the Hard Disk Drive
For Model B computers:
7. Remove screws &
22
8. Pull the tab upward and lift the assembly
9. Remove the 4 screws
cover.
10. Reverse the process to install any new hard disk.
24
from the hard disk assembly.
23
out of the computer.
24
- to release the hard disk from the assembly
25 28
22
23
25
28
27
26
