Euphonix Max Air Control Surface Manual
Dimensions
75.00°
0
.900
23.400
24.300
Dimensions in inches
16.13
15.625
Figure 10 Side Dimensions
1/4-20 THREADED
INSERT 8 PLACES
Figure 11 CM416 Bottom Dimensions
17
KEEP CLEAR FOR
VENTILATION
KEEP CLEAR FOR
VENTILATION
16.25
8.39
6.78
3.06
2.06
1.20
0
0
.902
11.723
12.827
23.648
24.300
