Euphonix Max Air Control Surface Manual
Display Test
Clear All
Char Up
Char Down
Char E
Char W
Enumerate
Memory Test
ROM Test
This test reads the ROM and computes and displays the checksum. The user/tester can
match the checksum to a known good checksum (see below) to make sure ROM test is
successful.
CM404 Checksum - 6514
CM416 Checksum - D308
RAM Test
This tests the upper unused portion of the CPU board RAM. The Pass display shows
up when the test is done.
PC104 RAM Test
This test writes and reads the whole PC104 RAM and checks for errors. The Pass dis-
play shows up when the test is done.
11
