Euphonix Max Air Control Surface Manual
Technical Specifications
Power
Voltage
Power Consumption
Inrush Current
Fuse
Heat Dissipation
Environmental Requirements
Operating Temperature
Storage Temperature
Humidity
90–254 VAC (RMS), 50/60 Hz
2 x 50 W per module
1.0 A (US 117 V)
0.5 A (Europe 230 V)
1.0 A (Japan 100 V)
25 A
T5 A
CM404
520 BTU/hr
CM416
600 BTU/hr
CM416H
520 BTU/hr
0–35 C (Ambient)
-10 to 55 C
0–90% non-condensing
16
