Intergraph TD-x20 Setup Manual page 17

Game/MIDI
Ethernet
Keyboard/
Mouse
Parallel
NOTE The ports on the back on the base unit are labeled using PC 97 compliant icons.
7. For a desktop system, set the AC voltage switch to the proper line voltage for your
location. If you do not know the proper line voltage for your location, contact your local
power utility.
For a deskside system, the proper line voltage is detected and set automatically by the
power supply.
WARNING If you do not set the AC voltage switch correctly, serious equipment damage may
result when you turn on power to the system.
WARNING Make sure the power switch on the front of the base unit is OFF (in the out position).
If the power switch is engaged, serious equipment damage may result when you plug
the power cord into an AC outlet.
8. Connect the power cords for the monitor and base unit to an Uninterruptible Power
Supply (UPS) or to a grounded three-prong AC wall outlet. Then connect the power
cords to the base unit and to the monitor.
USB
Audio
SCSI
COM1
COM2
Video Out
5
