Setting Up The System Hardware - Intergraph TD-x20 Setup Manual

u
The location should maintain a temperature range of 10 C to 26 C (50 F to 80 F);
the optimum operating temperature is 21 C (70 F).
u
The location should maintain a humidity range from 20 percent to 80 percent non-
condensing; the optimum humidity level is 50 percent.

Setting Up the System Hardware

To set up the system hardware:
1. If setting up a deskside system, or if setting up a desktop system in a vertical orientation,
place the footstands on the bottom of the base unit. Place the back footstand between the
ribs on the back and side of the base unit. The following figure shows placement of the
footstands on a desktop system.
WARNING To avoid personal injury or equipment damage, and to allow proper airflow, you must
use the footstands when placing a desktop base unit in a vertical orientation.
NOTE Ensure the CD-ROM drive is at the top when placing a desktop base unit in a vertical
orientation.
Feet
Feet
3
