38
6. After closing the base unit, install the device drivers and configure the device according
to the vendor's instructions, if necessary.

Adding External SCSI Devices

Desktop systems are equipped with an Ultra SCSI controller for all SCSI devices. If you
install a non-Ultra SCSI device, data transfer rates are limited to the device's speed.
Deskside systems are equipped with a separate Ultra SCSI controller for external SCSI
devices. If you install a non-Ultra SCSI device, data transfer rates are limited to the device's
speed.
CAUTION Connecting a non-compliant SCSI-1 device to a TD-x20, TD-x25, TDZ-x20, or TDZ-x25
system may cause your system to stop working, or lead to other unpredictable results.
You can add up to five external single-ended SCSI devices to a desktop workstation, and up
to seven external single-ended SCSI devices to a deskside workstation. The total length of
the external SCSI cables depends on the number of devices connected to the SCSI adapter.
Peripheral
Power
Brace
Connector
SCSI Cable Red Stripe
