Intergraph TD-20 Setup Manual page 58

46
TD-200
Address (hex)
0000 - 000F
0020 - 0021
002E - 002F
00A0 - 00A1
00C0 - 00DE
0170 - 0177
01F0 - 01F7
0200 - 0207
0278 - 027F
02E8 - 02EF
02F8 - 02FF
0330 - 0331
0378 - 037F
03BC - 03BF
03E8 - 03EF
03F8 - 03FF
03B4 - 03B5
03BA
03C0 - 03CA
03CC
03CE - 03CF
03D4 - 03D5
03DA
03F0 - 03F5
0CF8 - 0CFB
0CFC - 0CFF
0FF0 - 0FF7
FF00 - FF07
FFA0 - FFA7
FFA8 - FFAF
Description
DMA 1
Interrupt controller 1
I/O controller configuration registers
Interrupt controller 2
DMA 2
Secondary IDE channel
Primary IDE channel
Audio / game port
Parallel port LPT2
Serial port COM4 / video (8514A)
Serial port COM2
MPU-401 (MIDI)
Parallel port LPT1
Parallel port LPT3
Serial port COM3
Serial port COM1
Video (VGA)
Video (VGA)
Video (VGA)
Video (VGA)
Video (VGA)
Video (VGA)
Video (VGA)
Floppy channel 1
PCI configuration address register
PCI configuration data register
CS4236 audio control
IDE bus master register
Primary bus master IDE registers
Secondary bus master IDE registers
